The CAPBs® device set including the CAPBs® interface basic is a display unit for all CAPBs® sens.
Modular display unit for all CAPBs® sens. The sensors can either be installed on top or bottom side. The 2.4" screen shows directly the measured values of the installed CAPBs® sensor. Via the CAPBs® device QR code generator or Bluetooth® the values could be transferred to the EuroSoft® live app to create professional measurement reports. The instrument is equipped with three navigation keys, magnets at the rear of the housing and a integrated beeper for audible signals.
| Scope of delivery | |
| M093000100 |
CAPBs® device |
| M094003910 |
CAPBs® interface basic |
| 524697 |
Data cable |
| 523493 |
USB mains unit |
| 524740 |
Box |
| General data CAPBs® device basic |
|
| Dimensions H x W x D |
155 x 62 x 42 mm |
| Weight |
approx. 220 g |
| Material housing |
Plastic (PC+ABS) |
| Display type |
2.4" TFT (240 x 320 pixels) |
| Operating temperature |
0 to 40 °C |
| Storage temperature |
-20 to 50 °C |
| Data interface |
Bluetooth® (range: 50 m), QR code |
| Power supply |
USB-C mains unit |
| Battery type |
Rechargeable lithium-ion battery 3.6 V / 1,600 mAh |
| CAPBs sens exchangeable |
yes |
| Ingress protection rating |
IP54 with plugged in CAPBs sens (for water application) and interface (DIN EN IEC 60529) |
The free EuroSoft® live App allows to transmit measured values to iOS and Android smartphones or tablets via QR code or Bluetooth®.
Software for processing and visualisation of measurement results and logs of CAPBs® measuring instruments.
Universal base handle for all CAPBs® sens sensor units, with direct Bluetooth® connection to the EuroSoft® live app, which is available on both the Android and iOS platforms.
